रेक्सरोथ हाइड्रोलिक दबाव कम करने वाला वाल्व

01

02

03

04

05

06

07

08

09

10

11

12

13

14

3DREP

6

‒

2X

/

E

G24

/

*

01

3-वे संस्करण में आनुपातिक दबाव राहत वाल्व

3DREP

02

बाहरी एनालॉग इलेक्ट्रॉनिक्स के लिए

कोई कोड नहीं

एकीकृत नियंत्रण इलेक्ट्रॉनिक्स के साथ

E

03

आकार 6

6

संस्करण

04

टाइप 3DREP6 A 2X/..

A

टाइप 3DREP6 B 2X/..

B

टाइप 3DREP6 C 2X/..

C

05

घटक श्रृंखला 20 ... 29 (20 ... 29: अपरिवर्तित स्थापना और कनेक्शन आयाम) - आकार 6

2X

दाब मूल्यांकन

06

16 बार

16

25 बार

25

45 बार

45

07

वियोज्य कुंडल के साथ आनुपातिक सोलनॉइड

E

बिजली की आपूर्ति

08

डायरेक्ट वोल्टेज 24 वी

G24

09

बिनामैनुअल ओवरराइड

कोई कोड नहीं

साथछिपा हुआ मैनुअल ओवरराइड

N9³⁾

10

बिना विशेष प्रकार की सुरक्षा के

कोई कोड नहीं

समुद्री जल प्रतिरोधी

J²⁾

बिजली का संपर्क

11

DREP प्रकार के लिए:

बिनासहवास योजक; कनेक्टर DIN EN 175301-803

K4¹⁾

DREPE प्रकार के लिए:

बिनासहवास योजक; कनेक्टर DIN EN 175201-804

K31¹⁾

विद्युत इंटरफ़ेस

12

DREP प्रकार के लिए:

कोई कोड नहीं

DREPE प्रकार के लिए:

कमांड मान/वास्तविक मान ±10 V

A1

कमांड मान/वास्तविक मान 4…20 एमए

F1

सील सामग्री

13

एनबीआर सील

M

एफकेएम सील

V

14

सादे पाठ में अधिक विवरण

*

¹⁾

संस्करण "J"=के लिए केवल समुद्री जल-प्रतिरोधी indiSAARe "K31"

²⁾

केवल संस्करण 3DREP6 के लिए

³⁾

संस्करण "J" के साथ, indiSAARe केवल "N9" के बजाय "N"

अनुरोध पर विशेष विद्युत प्रकार की सुरक्षा

R900954422

3DREPE6A-2X/16EG24K31/A1M

R901045206

3DREPE6A-2X/16EG24K31/F1M

R901013558

3DREPE6A-2X/16EG24N9K31/A1M

R901123196

3DREPE6A-2X/16EG24N9K31/A1V

R901418062

3DREPE6A-2X/16EG24N9K31/F1V

R900954423

3DREPE6A-2X/25EG24K31/A1M

R900967164

3DREPE6A-2X/25EG24K31/A1V

R901069746

3DREPE6A-2X/25EG24K31/F1M

R901010399

3DREPE6A-2X/25EG24N9K31/A1M

R900925526

3DREPE6A-2X/25EG24N9K31/A1V

R901033013

3DREPE6A-2X/25EG24N9K31/F1M

R900975912

3DREPE6A-2X/25EG24N9K31/F1V

R900954424

3DREPE6A-2X/45EG24K31/A1M

R900717553

3DREPE6A-2X/45EG24K31/A1V

R901051881

3DREPE6A-2X/45EG24N9K31/A1M

R900943289

3DREPE6A-2X/45EG24N9K31/A1V

R900978110

3DREPE6A-2X/45EG24N9K31/F1M

R901006909

3DREPE6A-2X/45EG24NJK31/A1M

R900954485

3DREPE6A {{2}

R901045208

3DREPE6A {{2}

R901013571

3DREPE6A {{2}

R901123191

3DREPE6A {{2}

R901418063

3DREPE6A {{2}

R900954486

3DREPE6A {{2}

R900967303

3DREPE6A {{2}

R901069751

3DREPE6A {{2}

R901010402

3DREPE6A {{2}

R900930257

3DREPE6A {{2}

R901033016

3DREPE6A {{2}

R900976058

3DREPE6A {{2}

R900954487

3DREPE6A {{2}

R900717554

3DREPE6A {{2}

R901051884

3DREPE6A {{2}

R900944177

3DREPE6A {{2}

R900978612

3DREPE6A {{2}

R901006917

3DREPE6A {{2}

R901060430

3DREPE6B-2X/16EG24K31/A1M

R900956182

3DREPE6B-2X/25EG24K31/A1M

R900967160

3DREPE6B-2X/25EG24K31/A1V

R900959338

3DREPE6B-2X/25EG24K31/F1M

R901014844

3DREPE6B-2X/25EG24K31/F1V

R900955862

3DREPE6B-2X/25EG24N9K31/A1M

R900931050

3DREPE6B-2X/25EG24N9K31/A1V

R901076954

3DREPE6B-2X/25EG24N9K31/F1M

R900943943

3DREPE6B-2X/25EG24N9K31/F1V

R901060431

3DREPE6B-2X/45EG24K31/A1M

R901100346

3DREPE6B-2X/45EG24K31/F1M

R901016018

3DREPE6B-2X/45EG24N9K31/A1M

R900925013

3DREPE6B-2X/45EG24N9K31/A1V

R900929865

3DREPE6B-2X/45EG24N9K31/A1V=LB

R901312055

3DREPE6B-2X/45EG24N9K31/F1M

R901081245

3DREPE6B-2X/45EG24NJK31/A1M

R901060432

3DREPE6B {{2}

R900959332

3DREPE6B {{2}

R900967557

3DREPE6B {{2}

R900959339

3DREPE6B {{2}

R901014845

3DREPE6B {{2}

R900959333

3DREPE6B {{2}X =25 EG24N9K31/A1M

R900932157

3DREPE6B {{2}

R901076955

3DREPE6B {{2}

R900944584

3DREPE6B {{2}

R901060433

3DREPE6B {{2}

R901100344

3DREPE6B {{2}

R901016016

3DREPE6B {{2}X =45 EG24N9K31/A1M

R900930259

3DREPE6B {{2}

R901081248

3DREPE6B {{2}

R900954425

3DREPE6C-2X/16EG24K31/A1M

R901003312

3DREPE6C-2X/16EG24K31/F1M

R901003121

3DREPE6C-2X/16EG24K31/F1V

R901015676

3DREPE6C-2X/16EG24N9K31/A1M

R900700593

3DREPE6C-2X/16EG24N9K31/A1V

R900782219

3DREPE6C-2X/16EG24N9K31/F1M

R900976079

3DREPE6C-2X/16EG24N9K31/F1V

R901108008

3DREPE6C-2X/16EG24NJK31/F1M

R901212436

3DREPE6C-2X/16EG24NJK31/F1V

R901395470

3DREPE6C-2X/25EG24JK31/F1V

R900954427

3DREPE6C-2X/25EG24K31/A1M

R900925527

3DREPE6C-2X/25EG24K31/A1V

R900973913

3DREPE6C-2X/25EG24K31/F1M

R900955853

3DREPE6C-2X/25EG24K31/F1V

R961012812

3DREPE6C-2X/25EG24K31/F1V*ET

R901218809

3DREPE6C-2X/25EG24N6K31/A1M

R900955784

3DREPE6C-2X/25EG24N9K31/A1M

R961005245

3DREPE6C-2X/25EG24N9K31/A1M*ET

R900925484

3DREPE6C-2X/25EG24N9K31/A1V

R961005248

3DREPE6C-2X/25EG24N9K31/A1V*ET

R901018511

3DREPE6C-2X/25EG24N9K31/A1V=LB

R900958848

3DREPE6C-2X/25EG24N9K31/F1M

R961005244

3DREPE6C-2X/25EG24N9K31/F1M*ET

R900926984

3DREPE6C-2X/25EG24N9K31/F1V

R961005247

3DREPE6C-2X/25EG24N9K31/F1V*ET

R900766917

3DREPE6C-2X/25EG24NJK31/A1M

R961005249

3DREPE6C-2X/25EG24NJK31/A1M*ET

R901107152

3DREPE6C-2X/25EG24NJK31/F1M

R900948409

3DREPE6C-2X/25EG24NJK31/F1V

R961005246

3DREPE6C-2X/25EG24NJK31/F1V*ET

R900954428

3DREPE6C-2X/45EG24K31/A1M

R901094369

3DREPE6C-2X/45EG24K31/A1V

R900706205

3DREPE6C-2X/45EG24N9K31/A1M

R900963713

3DREPE6C-2X/45EG24N9K31/A1V

R901012117

3DREPE6C-2X/45EG24N9K31/F1M

R900970698

3DREPE6C-2X/45EG24N9K31/F1V

R900785794

3DREPE6C-2X/45EG24NJK31/A1M

R900954488

3DREPE6C {{2}X =16 EG24K31/A1M

R901003315

3DREPE6C {{2}

R901003157

3DREPE6C {{2}

R901015677

3DREPE6C {{2}X =16 EG24N9K31/A1M

R900717942

3DREPE6C {{2}X =16 EG24N9K31/A1V

R900782220

3DREPE6C {{2}

R900700514

3DREPE6C {{2}

R901115821

3DREPE6C {{2}

R901212434

3DREPE6C {{2}

R900954489

3DREPE6C {{2}X =25 EG24K31/A1M

R900930263

3DREPE6C {{2}

R900973965

3DREPE6C {{2}

R900956684

3DREPE6C {{2}

R901439992

3DREPE6C {{2}X =25 EG24N5K31/A1M

R901218805

3DREPE6C {{2}X =25 EG24N6K31/A1M

R900958788

3DREPE6C {{2}X =25 EG24N9K31/A1M

R901123602

3DREPE6C {{2}

R900930264

3DREPE6C {{2}X =25 EG24N9K31/A1V

R900938345

3DREPE6C {{2}

R900958859

3DREPE6C {{2}

R900930265

3DREPE6C {{2}

R900766916

3DREPE6C {{2}

R901107153

3DREPE6C {{2}

R900948830

3DREPE6C {{2}

R900954490

3DREPE6C {{2}X =45 EG24K31/A1M

R901094368

3DREPE6C {{2}

R901004594

3DREPE6C {{2}X =45 EG24N9K31/A1M

R900963721

3DREPE6C {{2}X =45 EG24N9K31/A1V

R901012120

3DREPE6C {{2}

R900970699

3DREPE6C {{2}

R901001163

3DREPE6C {{2}
